ZANUO (ZN-NVR1108M) 10 KANAL 1x14TB HDD DESTEKLİ 8MP KAMERA DESTEKLİ 4K NVR KAYIT CİHAZI

ZANUO (ZN-NVR1108M) 10 KANAL 1x14TB HDD DESTEKLİ 8MP KAMERA DESTEKLİ 4K NVR KAYIT CİHAZI

Marka Dahua

Teknik Özellikler

Kategori NVR Kayıt Cihazı
HDD 1x14 TB HDD
Disk Sayısı 1
Kanal Sayısı 10
Ethernet Arayüzü 10/100 Mbps
PoE Yok
HDMI Bağlantısı 1
Video Girişi IP
VGA Bağlantısı Var
Genel Stok Var
Fiyat
Satış Fiyatı $ 62,793.097,79 TL€ 56,11 + KDV
Havale Fiyatı $ 60,913.004,86 TL€ 54,43 + KDV

NOT : Cihazınız 8 Kanal olarak gelmektedir. 10 Kanal olması için aşağıdaki linkten 1 Serisi NVR güncelleme dosyasını indiriniz.
Güncelleme Dosyaları İçin Tıklayınız
Max.128 Mbps bandwidth; Max 10 Channel 8MP IPC input;
4-channel 1080P decoding capability;
Support 4K HDMI output; Up to 10 channels for playback;
Support P2P, APP Alarm Push; Support AI search;
AI by camera: Face Detection, Intrusion, Tripwire (classification of human/vehicles /non-motor), Object Detection, and SMD

System
OS Embedded Linux
OS Operation Interface Web/operating in local GUI
Perimeter Protection by Camera
Performance Support
Face Detection by Camera
Performance Support
SMD by Camera
Performance Support
Video & Audio Input
Max bandwidth 128Mbps
IPC Input 10 CH
Video & Audio Output
VGA 1920×1080,1280×1024,1280×720
HDMI 3840×2160,1920×1080,1280×1024,1280×720
Audio Output 1CH, RCA (Line out,2Vp-p,300ohms)
Audio Encoding
Audio Compression G.711A
Audio Bit Rate 8Kbps(16bit)
Video&Audio Decoding
IP channel Resolution Up to 3840×2160
Video decoding H.265(Main Profile@L5.0 High-tie)/H.264 Up to High Profile@Level5.0)
Audio decoding G.711A, G711U, G726
Synchronous Playback 10CH
Decoding Ability 4CH 1080P@30FPS/1CH 4K@30FPS
Preview
Synchronous Preview 10
Multi-screen Display 1, 4, 9,16 views
Playback
Record Mode  Manual; Schedule (general; MD; alarm; intelligent)
AI Search Search by target classification (human, vehicle, non-motor vehicle)
Backup USB device
Playback Function 1. Play; pause; stop; fast forward; fast backward; rewind; play by frame
2. Full screen; backup (cut/file); partially enlarge; audio on/off
Network
Network Protocol HTTP; TCP/IP; IPv4; UPnP; SNMP; RTSP; UDP; SMTP; NTP; DHCP; DNS; IP Filter; DDNS; FTP; P2P; Auto register
Mobile Phone Access Android; iOS
Interoperability ONVIF; SDK
Browser IE8 or later
HDD
SATA 1
ESATA 0
Max Capacity 10 TB for each
External Interface
PoE Ports 0
Network Interface 1 RJ45 100M
VGA 1
HDMI 1
CVBS 0
USB 2*USB2.0 on Back Panel
RCA Input 1
RCA Output 1
Alarm Input 0
Alarm Output 0
RS-232 0
RS-485 0
Other Function
Two-way Talk Yes
Alarm Linkage Record; Snapshot; Buzzer; Log; Preset; Email
Picture Capture Support JPEG Capture
General Parameter
Front Panel M
Packing 295mmx300mmx120mm
Dimensions Mini 1U 255mmx222mmx42mm
Weight 0.9Kg(No HDD)
Installation Desktop Installation
Power Supply DC 12V 2A
Working Temperature -10?–+55?
Working Humidity 10%–90%
Consumption 7W (without HDD)
Certifications
Certifications CE/FCC
