4MP 1/3″ CMOS Sensor
l Support H.264, H.265
l IR Light: 20 m, Warm Light: 20m
l Support Built-in Mic & Speaker
l Support 802.11b/g/n/ax 2.4GHz Wi-Fi6
l 2.8mm fixed lens (3.6mm optional)
l 5 VDC power supply
| Camera | |
| Image Sensor | 1/2.8” CMOS |
| Max. Resolution | 4MP |
| Scanning System | Progressive |
| Electronic Shutter Speed | Auto(1/25s ~ 1/1000) |
| Min. Illumination | 0.01 Lux @F2.0 |
| S/N Ratio | > 56 dB |
| Illumination Distance | IR Light: 20 m, Warm Light: 20m |
| Illuminator Control | Auto; Manual |
| Lens | |
| Lens Type | Fixed-Focal |
| Focal Length | 2.8mm/3.6mm |
| Max. Aperture | F2.0 |
| Intelligence | |
| SMD | Support |
| Auto Tracking | NA |
| Video | |
| Compression | H.264H; H.264M; H.264B; H.265 |
| Video Frame Rate | Main Stream: 4MP (1 fps–25/30 fps) |
| Sub Stream: D1 (1 fps–25/30 fps) | |
| Stream Capability | 2 Streams |
| Bit Rate Control | CBR/VBR |
| Video Bit Rate | H.264: 1792Kbps~4Mbps |
| H.265: 1792Kbps~4Mbps | |
| Day/Night | Color/B/W |
| BLC | Yes |
| HLC | Yes |
| WDR | DWDR |
| White Balance | Yes |
| Gain Control | Auto/Manual |
| Noise Reduction | 3D NR |
| Motion Detection | OFF/ON (4 Areas, rectangular) |
| Image Rotation | 0°/180° |
| Mirror | Yes |
| Privacy Masking | 4 Areas |
| Audio | |
| Built-in Mic | Yes |
| Built-in Speaker | Yes |
| Two-way talk | Yes |
| Audio Compression | G.711a; G.711Mu; G.726; G.726ASF |
| Alarm | |
| Alarm Event | Disconnection; IP Conflict; No SD Card; Capacity Warning; SD Card Error |
| Network | |
| Network | RJ-45 (10/100 Base-T) |
| WiFi | 802.11b/g/n/ax 2.4GHz Wi-Fi6,20/40MHz bandwidth |
| SDK and API | Yes |
| Network Protocol | TCP/IP;UDP;HTTP;DHCP;DDNS;FTP;UPNP |
| Interoperability | CGI |
| Storage | SD Card |
| Browser | IE: IE8 and later |
| Management Software | PC Software(SVMS) |
| Mobile Client | IOS; Android |
| Power | |
| Power Supply | 5V DC (±30%) |
| Power Consumption | Max. 3W |
| Environment | |
| Operating Conditions | –10°C to +45°C /Less than 95% RH |
| Storage Conditions | –40°C to +60°C |
| Protection Grade | NA |
| Structure | |
| Casing | Plastic |
| Dimensions | 119mm×Φ77 mm |
| Net Weight | 420g |
